High Speed Power Meter 119
A Technical Specifications
I
MPORTANT
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
SPECIFICATIONS a (IQS-1600 Series)
Model IQS-1613/1623/1643 IQS-1613-PL/1623-PL/1643-PL IQS-1613W/1623W/1643W
Number of detectors 1/2/4 1/2/4 1/2/4
Detector type InGaAs InGaAs InGaAs
Detector size (mm) 1 1 3
Wavelength range (nm) 800 to 1700 800 to 1700 800 to 1700
Power range b, j (dBm) 9 to −85 9 to −85 8 to −75
Uncertainty c (%) ±5 ±5 ±5
(0 dBm to −55 dBm) (0 dBm to −55 dBm) (0 dBm to −50 dBm)
Polarization dependent responsivity d (dB) N/A ±0.005 N/A
Linearity e (dB) ±0.015 (0 dBm to −55 dBm) ±0.015 (0 dBm to −55 dBm) ±0.015 (0 dBm to −50 dBm)
Power resolution (dB) 0.001 (9 dBm to −40 dBm) 0.001 (9 dBm to −40 dBm) 0.001 (8 dBm to −40 dBm)
Wavelength resolution (nm) 0.01 0.01 0.01
Stabilization time (ms)
automatic range < 12 (9 dBm to −85 dBm) < 12 (9 dBm to −85 dBm) < 6 (8 dBm to −75 dBm)
automatic range < 3 (9 dBm to −50 dBm) < 3 (9 dBm to −50 dBm) < 3 (8 dBm to −49 dBm)
fixed range (ranges 1 to 4) < 1 < 1 < 1
Sampling rate (sample/s/channel)
fast acquisition mode up to 4096 up to 4096 up to 4096
continuous measurement mode up to 256 up to 256 up to 256
Fiber type (μm) 5/125 to 62.5/125 5/125 to 62.5/125 5/125 to 62.5/125
