Managing Results
302
FTB-5240S/S-P/BP
Managing EDFA Test Results
Results Tab
The results table shows channel results for both the input or output traces.
The results for only the channels within the scan range will be displayed.
To view results:
From the main window, select the Results tab.
For information on each item, see Customizing EDFA Results Table on
page 213.
A small red marker ( ) will point down at the peak in the EDFA Graph tab
when you select a row in the Results tab. The red marker will move
accordingly to indicate the corresponding peak on the graph, with a focus
on the selected channel.
