EXFO FTB -5240S/5240BP Optical Spectrum Analyzer User Manual
Page 193
Setting Up the Instrument in Spectral Transmittance Mode
OSA
187
Setting Up Spectral Transmittance Analysis Parameters
5. Select the background color scheme for the graph as desired.
6. Press OK to save the changes and close the window, or press Cancel to
exit without saving.
Press Restore Defaults to remove all the changes and apply the default
values.
Setting Up Spectral Transmittance Analysis
Parameters
This section presents the various analysis settings for the application. These
settings are applied on subsequent acquisitions/re-analyses.
Note: When you change the analysis setup parameters, the new settings are
active as soon as you confirm your choice. The current trace is re-analyzed,
and the analysis setup parameters will be applied to the global results and
channel results for the following acquisitions.
You can either set each parameter individually, or use parameters from the
current trace and import them.
