Managing Results
280
FTB-5240S/S-P/BP
Managing Drift Test Results
Channel Graph Tab
The Channel Graph tab displays three different graphs for the selected
channel. You can select which graphs you want to display from the Drift
Results tab in the Preferences Window. The three graphs are X-Y plots of:
Spectral position (center of mass of wavelength or frequency) of the
channel over time
Signal power of the channel over time
OSNR of the channel over time
