DI-206 ISDN Remote Router
Configuration and Management 77
•
Src Netmask – This mask is bit-wise AND’d with the source IP
address and bit-wise AND’d with the IP address of the incoming
interface. The two results are then compared.
•
Dst IP – This is the destination address in the IP header of the
packet.
•
Dst Netmask – This mask is bit-wise AND’d with the destination
IP address and bit-wise AND’d with the IP address of the incoming
interface. The two results are then compared.
•
Dst Port – This is the destination port, in the TCP or UDP header,
of the packet.
•
Operation – This comparison operation is applied to the destination
port (the Dst Port parameter) value, of the TCP or UDP header.
•
ICMP Type – This is the type field, in the ICMP header, used to
identify a particular ICMP message.
•
ICMP Code – This is the code field, in the ICMP header, used to
further specify the ICMP type.
•
TCP Flag – This is a hex number, representing the six flag bits in the
TCP header. The value range is from 0 to 3F.
Multiple Home Configuration
Besides the IP address assigned to the LAN interface in the Network
Configuration menu, the LAN may have up to 3 additional IP
interfaces. These additional IP interfaces are referred to as MIP1 to
MIP3. This type of configuration is known as a multiple home
configuration.
