DI-206 ISDN Remote Router
92 Configuration and
Management
Dynamic NAT
This screen (below) is how the NAT IP Pool appears, if Dynamic NAT
was chosen for the Translation Mode parameter. Each entry, in this
configuration, can be used to map multiple, contiguous global addresses
and local addresses to each other.
The parameters are described below:
•
Global IP – An IP Address that is globally unique and valid on the
Internet. It is the base, global address for the global addresses that
will be recognized by the interface in the Global Interface parameter.
•
Range – This is the range of contiguous, global addresses above
(and including) the base Global IP.
•
Local IP – An IP Address that is only used in the stub domain since
it is not unique. It is the base, local address for the local addresses
