DI-206 ISDN Remote Router
Installation
15
HyperTerminal, included with Windows). The terminal emulation
software needs to be configured to the following parameters:
◊
VT100 terminal emulation
◊
9600 baud
◊
No parity, 8 data bits, 1 start bit, 1 stop bit
◊
No flow control
Step 2 - Connecting the Console to the Router
A serial cable is included in the DI-206 package. To connect this
cable, plug its nine-pin connector into the 9-pin RS-232 Diagnostic port
on the router’s rear panel, then connect the other end to the serial port
on the rear of your computer or data terminal.
Please make sure both machines are turned off before making this
connection.
After the connection is made, first power on the console. If you are
using a PC, run the terminal emulation software at this time. After the
PC and the terminal emulation software are up and running, power on
the router.
Using the Console
The Console Program is the interface that you will be using to configure
your DI-206. Several operations that you should be familiar with before
you attempt to modify the configuration of your router are listed below:
♦
Moving the Cursor Within a menu, use
to navigate through different information fields.
