DI-206 ISDN Remote Router

16

Installatio

n

Moving Forward to Another Menu To move forward to a

sub-menu below the current one, use or arrow keys to
position the cursor on the sub-menu item and press to
view the selected sub-menu.

Entering Information There are two types of fields that you

will need to fill in. The first requires you to type in the appropriate
information. The second gives you choices to choose from. In the
second case, press the space bar to cycle through the available
choices. Upon configuring all fields the sub-menu, position the
cursor on SAVE and press to save, or position the
cursor on EXIT to cancel.

Refresh Screen Console screens are notorious for becoming

garbled. When this happens, simply press + to
refresh the contents of the screen.

Step 3 - Connecting an ISDN Line to the Router

Your phone company will provide an S/T interface into your home or
office. Plug the ISDN line from the router directly into the ISDN wall
socket provided by your phone company.

Step 4 - Connecting a Telephone or Fax Machine to the Router

You can connect a regular telephone, fax machine, or modem to your
router to be used for analog calls. Note that the router’s other functions
all work the same whether you connect an analog device or not.
