DI-206 ISDN Remote Router

Installation

21

To log on to the router, use the factory set username and password
“Admin” (without the quotes). Please note that the user name and
password are case-sensitive.

Upon entering the username and password (using the key to
jump to the next field), position the cursor on OK and press .
You will then see the following Main Menu:

Step 7 - Configuring the LAN Port

Preparing the router for connection to a LAN only requires enabling the
LAN port, enabling IP networking, assigning the LAN port an IP
address and enabling Telnet (if necessary). After the LAN port is
configured, all other features on the router can be configured remotely
through the LAN by using the included Windows-based Router
