DI-206 ISDN Remote Router

Installation

17

To connect an analog device, just plug one end of the device’s cord
into one of the sockets on the back of the router marked PHONE 1 or
PHONE 2.

To have incoming calls directed to a device on a PHONE jack, you
must enter the telephone number for the phone in the console program
under the Interface Configuration, ISDN submenu.

Step 5 - Connecting Ethernet Cables to the Router

Your DI-206 has six ports for connecting 10BASE-T Ethernet devices
to form a LAN. The jacks for ports 1 through 5 are wired to let you
connect network end nodes (computers, servers, bridges, other routers,
etc.) using standard “straight-through” EIA (Electronic Industries
Association) Category 3 or higher twisted-pair cables. The jack for the
sixth port is labeled Uplink and is wired to let you connect to another
10Mbps Ethernet or dual-speed hub using a straight-through cable, or
an end node using a cross-wired cable.

Please refer to the following chart when deciding on the type of cable
necessary for a given connection:

DEVICE

PORT
USED

DEVICE BEING

CONNECTED

PORT

TYPE

CABLE TO USE

Hub or

Norma

l

Crossover (X)

Norma

l

Switch

Uplink

Straight-Through (||)

Router

Server (or PC)

Straight-Through (||)

Hub or

Norma

l

Straight-Through (||)
