DI-206 ISDN Remote Router

76

Configuration and

Management

The IP Filter parameters are described below:

Name – This is a 12 character (maximum), alphanumeric, user-

defined name, used to identify the filter.

Direction – This defines the direction of the packet relative to the

Interface parameter below.

State – This is used to define the routing decision applied to the

packet. The three routing decisions are described:

1. forwardThis allows the routing of the packet, if it has met the

criteria of the corresponding filter.

2. drop This drops (doesn’t allow routing for) a specific packet

that has met the criteria of the corresponding filter.

3. disable – This does not apply the IP filter.

Interface – This applies the filter to a specific interface, LAN or

one of the ISDN interfaces.

Protocol Type – This is a protocol identifier, as assigned by the

Internet Assigned Numbers Authority (IANA). The values of this
identifier are described in RFC-1700. This router supports the
following:

1 This is Internet Control Message (ICMP), defined in RFC 792.

6 This is Transmission Control (TCP), defined in RFC 793.

17 This is User Datagram (UDP), defined in RFC 798.

Src IP – This is the source address in the IP header of this packet.
