DI-206 ISDN Remote Router
Configuration and Management 117
•
Rx CRC Packets – The number of packets received that failed the
CRC checksum test.
•
Rx Overrun Packets – The number of packets received that
exceed the 1518 octet maximum length imposed on Ethernet
packets. Overrun packets are generated by some proprietary
software applications.
•
Rx CD Lost Packets – Carrier Detect Lost. This counts the
number of Carrier Detect packets that were lost by the router.
•
Rx Framing Error Packets – Packets with framing errors can
occur on the ISDN port only when using HDLC in sync mode. This
parameter counts the number of lost start/stop flags.
•
Rx Parity Error – The number of times parity errors occurred on
the line.
Runtime Tables
The Runtime Tables submenu features IP Routing Table, ARP
Table, and PPP Table:
