DI-206 ISDN Remote Router
22
Installatio
n
Configuration Utility or Telnet. Regardless, the router can always be
configured using a console connected to the RS-232 Console port.
To configure the LAN:
1. The LAN port must be enabled in the Interface Configuration
sub-menu.
♦
Choose Interface Configuration, LAN.
♦
Position the cursor over the State item and press .
The State will change from Disable to Enable.
♦
Position the cursor on the SAVE option at the bottom of the
screen and press to save the new setting.
♦
Choose Exit in the sub-menus to return to the Main Menu.
2. Enable IP Networking
♦
Choose Network Configuration, IP Configuration.
♦
Position the cursor over the third item IP Networking and
press to Enable it.
♦
Position the cursor on the Save option at the bottom of the
screen and press to save the new setting.
3. Assign an IP address to the LAN port in the Network
Configuration sub-menu of the Main Menu.
