HEATING & COOLING
5F,H
Open-Drive Compressors
HIGH-PRESSURE RELIEF VALVE AND
MANIFOLD COVER PLATE
SEAL COVER PLATE
OIL PRESSURE REGULATOR
NAMEPLATE
plugged
openings
FOR
interconnection
{NOT STANDARD)
CRANKCASE
HEATER
CASINGS
(PIPE CAP 1/2" FPT)
SUCTION SHUTOFF VALVE
3-1/8“ ODF
SUCTION MANIFOLD COVER
(REMOVE FOR ACCESS TO
SUCTION STRAINER)
PNEUMATIC
CONTROL
CONNECTION 1/4" IPS
OPENING
TO
CRANKCASE
1/4" IPS
CAPACITY CONTROL VALVE
ADJUSTING STEM
CONTROL
OIL
STRAINER
PLUG 5/8"-18
OIL
FILLER
PLUG
CRANKCASE DRAIN
DISCHARGE
SHUTOFF
VALVE
3-1/8" ODF
GAGE
CONNECTIONS
1/4" IPS
HIGH-PRESSURE
CONTROL
CONNECTION 1/4" IPS
LOW-PRESSURE
CONTROL
CONNECTION 1/4" IPS
CENTER MAIN BEARING
RETAINING SCREW ACCESS
OIL PUMP
ROTATION ARROW (TAG)
- CONTROL OIL PRESSURE
OIL LEVEL SIGHT GLASS
Fig. 7 — 5H80, 86; 8-Cylinder Compressors
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obiigations.
Book|2
PC 111
Catalog No 530-526
PrintedinUSA
Form 5F,H-11SI
Pg8
588
2-86
Replaces; 5F,H-9SI
For replacement items use Carrier Specified Parts
