KEATING A COOLING
5F,H
Open-Drive Compressors
o>
cf
PISTON RINGS { COMPRESSION - TAPERED )
igll.. Ill
CYLINDER SLEEVE
CYLINDER
SLEEVE
SNAP RING
% \
V ^
UNLOADER SPRINGS-»^ %
UNLOADER PINS
PISTON RING (OIL)
PISTON PIN
---- PISTON PIN LOCK RING
PISTON
PISTON RING (OIL)
CONNECTING ROD
CONNECTING ROD BOLTS
UNLOADER FORK
UNLOADER
POWER ELEMENT
UNLOADER
BRACKET
GASKET
SEAL END ---------------
BEARING WASHER
(BRONZE)
CONNECTING
ROD BEARING
INSERTS
ELASTIC LOCK NUT
ASSEMBLED
PISTON AND
CONNECTING ROD
CONNECTING
ROD CAP
CRANKSHAFT
SEAL END
THRUST
W A S H E R
(STEEL)
#
Fig. 22 — 5H Compressor Internal Components
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without ii^curring obligations.
Book
2
PC 111
Catalog No 530-526 PrintedinUSA Form5F,H-11SI
Pg
21
2-86
Replaces: 5F,H-9SI
Tab
2a
For replacement Items use
C a r r i e r
Specltied Parts.
