HCATINQ A COOLING
5F,H
Open-Drive Compressors
COVER PLATE WITH
INTEGRAL SEAL SEAT^
COVER PLATE GASKET'
BELLOWS
ASSEMBLY
FELT WIPER
COVER PLATE GASKET'
CARBON RING
SEAL NOSE
A — 5F20, 30 (Type I)
COVER PLATE WITH INTEGRAL SEAL SEAT
B — 5F40-5H86* (Type I) — Typical
*5F40 and 60 — 1.5" diameter; 5H40 through 86 — 2.0" diameter.
COVER PLATE GASKET
CARBON RING
SEAL NOSE
COVER PLATE WITH INTEGRAL SEAL SEAT
C — 5H120, 126 (Type II)
Fig. 50 — Service Replacement Seals
Table 13 — Accessory Literature
ACCESSORY
LITERATURE
AVAILABLE
Condensing Unit Piping
Accessory Control Panel
Accessory Compressor Crankcase Heater
Accessory Belt Drive Package
Flexible Couplings for Direct-Drive Units
Water-Cooled Condensers
Installation
Accessory Water-Cooled Heads Package
Accessory Oil Filter Package
Instructions*
Accessory Oil Cooler
Accessory Oil Safety Switch Package
Capacity Control Valve
Accessory Unloader Package
*See your Carrier Distributor for current form number.
Manufacturer reserves the right to discontinue, or change at any time, speciticatlons or designs without notice and without Incurring obligations.
Book
2
PC111
Catalog No 530-526 Printed in U S A. Form5F,H-11SI
Pg 35
2-86
Replaces: 5F,H-9SI
Tab
2a
For replacement items use Carrier Specified Parts.
