HKATtNG A COOLING

5F,H

Open-Drive Compressors

SUCTION

SHUTOFF

VALVE

I- I /8" ODF

OIL

FILLER

PLUG

5/8"-18

OIL

PRESSURE

CONNECTION'

1/4" IPS

OIL DRAIN PLUG 5/8"-18

GAGE

CONNECTION

1/4" IPS

OIL

PUMP

ROTATION

ARROWS

CRANKCASE

HEATER

CASING

(PIPE CAP 1/2" FPT)

PUMP INTAKE PLUG (MAGNETIC)

DISCHARGE

SHUTOFF.

VALVE-7/8^ ODF

GAGE

CONNECTION

1/4" IPS

SUCTION AND DISCHARGE

MANIFOLD COVER-REMOVE
FOR ACCESS TO SUCTION
STRAINER

SEAL COVER

OIL PRESSURE REGULATOR

OIL

PRESSURE

CONNECTION

5/8" - 18

OIL

LEVEL

SIGHT

GLASS

Fig. 1 — 5F20; 2-Cylinder Compressor

Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and wilhout incurring obligations.

PC111 Catalog No 530-526 PrintedinUSA Form 5F,H-11SI Pg2 588

2-86 Replaces: 5F,H-9SI

For replacement Items use Carrier Specified Parts

Book 12
