Appendix A: RTU Open Points/Properties
64 RTU Open
Default
Range: -40 to 245°F
Demand Level
Point Name/Description Occupied 1 2 3
Occupied Heating 2 – Dark Blue
The space temperature must be less than the Occupied Heating 2 setpoint to
generate a low space temperature alarm. We recommend that this value be set no
less than 0.5°F below the Occupied Heating 1 setpoint.
68°F 67°F 66°F 64°F
Occupied Cooling 1 – Yellow
The space temperature must be greater than the Occupied Cooling 1 setpoint for
the VVT Master to consider the zone a cooling caller in a linked system. In a single-
zone application, the cooling requirement begins as soon as the space
temperature exceeds the Occupied Cooling setpoint. We recommend that the
Occupied Cooling 1 value be set no less than 0.5°F above the Occupied Cooling
setpoint.
75°F 76°F 77°F 79°F
Occupied Cooling 2 – Orange
The space temperature must be greater than the Occupied Cooling 2 setpoint to
generate a high space temperature alarm. We recommend that this value be set
no less than 0.5°F above the Occupied Cooling 1 setpoint.
76°F 78°F 78°F 81°F
Unoccupied Setpoints
Point Name/Description Default/Range
Unoccupied Heating – Gray
The heating setpoint the controller maintains while in unoccupied mode.
D:
R: 55°F
45 to 100°F
Unoccupied Cooling – Gray
The cooling setpoint the controller maintains while in unoccupied mode.
D:
R: 90°F
-40 to 245°F
Unoccupied Heating 1 – Light Blue
The space temperature must be less than the Unoccupied Heating 1 setpoint for the VVT
Master to consider the zone an unoccupied heating caller in a linked system. In a single-zone
application, the unoccupied heating requirement begins as soon as the space temperature falls
below the Unoccupied Heating setpoint. We recommend that the Unoccupied Heating 1 value
be set no less than 0.5°F below the Unoccupied Heating setpoint.
D:
R: 54°F
-40 to 245°F
Unoccupied Heating 2 – Dark Blue
The space temperature must be less than the Unoccupied Heating 2 setpoint to generate an
unoccupied low space temperature alarm. We recommend that this value be set no less than
0.5°F below the Unoccupied Heating 1 setpoint.
D:
R: 52°F
-40 to 245°F
Unoccupied Cooling 1 – Yellow
The space temperature must be greater than the Unoccupied Cooling 1 setpoint for the VVT
Master to consider the zone an unoccupied cooling caller in a linked system. In a single-zone
application, the unoccupied cooling requirement begins as soon as the space temperature
exceeds the Unoccupied Cooling setpoint. We recommend that the Unoccupied Cooling 1 value
be set no less than 0.5°F above the Unoccupied Cooling setpoint.
D:
R: 91°F
-40 to 245°F
Unoccupied Cooling 2 – Orange
The space temperature must be greater than the Unoccupied Cooling 2 setpoint to generate an
unoccupied high space temperature alarm. We recommend that this value be set no less than
0.5°F above the Unoccupied Cooling 1 setpoint.
D:
R: 93°F
-40 to 245°F
