RTU Open 59
NOTE Engineering units shown in this document in the defaults and ranges are strictly for reference. You
must enter an integer only.
Status
Navigation: i-Vu / Field Assistant:
BACview: Properties > Equipment > Status
HOME > STATUS
Point Name/Description Range
System Mode – The controller's current operating status. R: Disabled
Test
Run
Operating Mode – The controller's current operating mode. R: Off
Fan Only
Economizer
Cooling
Heating
Dehumidification
Test
Shutdown
Unocc Free Cooling (NTFC)
Supply Fan Status – The current fan status if an input is configured for Fan Status. R: Off/Running
Space Temperature - Prime Variable – The space temperature value currently used for
control.
R: -56 to 245°F
Supply Air Temperature – Displays the current supply air temperature. R: -56 to 245°F
Outdoor Air Temperature – The outdoor air temperature value used for control. R: -56 to 245°F
Space Relative Humidity – The current space relative humidity if Configuration > Unit
Configuration > Input 1 (or 2) Function is set to Space RH Sensor.
R: 0 to 100%rh
Indoor Air CO2 – The current indoor air CO
2
concentration if the Configuration >Unit
Configuration > Input 1 (or 2) Function is set to IAQ Sensor.
R: 0 to 5000ppm
Outdoor Air CO2 – The current outdoor air CO
2
concentration if the Configuration >Unit
Configuration >Input 1 (or 2) Function is set to OAQ Sensor.
R: 0 to 5000ppm
Economizer Output – The current economizer output with respect to the outdoor air
damper (if equipped).
R: 0 to 100% Open
Appendix A: RTU Open Points/Properties
