Ch 6 GPS/GNSS 67
Note: When moving, the compass shows the direction of
travel to the target. When stationary, the compass
displays a heading to the target, based on the internal
compass. The internal compass can be calibrated from
the Settings menu located at Start > Settings > System >
Sensors.
„
Select the disc icon to save the waypoint to \My
Documents\My Waypoints.
Collect Track Data
From the main JSNav screen select the track icon to open
the Collect Track screen.
„
To collect points in a track, select the play key and
start moving along the desired track. Select the pause
key as needed, and select play to start again. Current
position information, total distance, altitude change, and
points in the track are collected.
„
When you are finished, select the stop key. A dialogue
box is shown with the track name. You can use that name
or edit it. Select the check mark when you are finished.
The track is saved in \My Documents\My Tracks.
„
Select the edit icon to add or edit the name,
description, notes, and file type for this track
