EVCO EPU2LXP1CH - Manual (Page 7)

EVCO S.p.A. c-pro 3 micro and c-pro 3 kilo | Hardware manual ver. 1.0 | Code 114CP3UKE104
page 7 of 62
10
RS-485 port with Modbus master communication protocol (available in models c-pro 3 micro+ and c-pro 3 kilo+
only)
11
micro-switch to plug in the termination of the RS-485 port with Modbus master communication protocol (available in
models c-pro 3 micro+ and c-pro 3 kilo+ only)
12 signalling LEDs
13
according to the model:
- digital outputs 8 (available in models c-pro 3 micro+ and c-pro 3 kilo+ only)
- unipolar stepper electronic expansion valves driver (available in models c-pro 3 micro+ and c-pro 3 kilo+
only)
