EVCO S.p.A. c-pro 3 micro and c-pro 3 kilo | Hardware manual ver. 1.0 | Code 114CP3UKE104
page 44 of 62
Diagnostic RTC parameter available in read only modality
clock status
ok = not in error
err = in error
low = loss of data
disab = disabled
Diagnostic STACK parameter available in read only modality
stack status
ok = not in error
err = in error (because of overflow)
Diagnostic 5V Ratio parameter available in read only modality
status of the power supply voltage of the
ratiometric transducers
ok = not in error
err = in error (because of out of
range voltage)
Diagnostic 12V Sensor parameter available in read only modality
status of the power supply voltage of the
0-20 mA / 4-20 mA / 0-10 V transducers
ok = not in error
err = in error (because of out of
range voltage)
Diagnostic Math parameter available in read only modality
Math status
ok = not in error
err = in error (because of overflow,
underflow, division by zero or
NaN)
Diagnostic Key Par parameter available in read only modality
result of the copy of the parameters from the
controller to the USB peripheral
ok = operation successful
completed
err = operazione failed
Debug
[ Algo ]
Main time parameter available in read only modality
main cycle time of the application software
(in milliseconds)
Max. time parameter available in read only modality
maximum main cycle time of the application
software (in milliseconds)
Free stack parameter available in read only modality
time of execution of the application software
temporized at 100 ms
Debug
[ CAN bus ]
100 ms time parameter available in read only modality
maximum time of execution of the
application software temporized at 100 ms
Max. time parameter available in read only modality
free stack of the interrupt cycle at 100 ms of
the application software (in byte)
