EVCO S.p.A. c-pro 3 micro and c-pro 3 kilo | Hardware manual ver. 1.0 | Code 114CP3UKE104
page 48 of 62
7.3. Vtouch
7.3.1. Introduction
Vtouch is a new and innovative user interface for the programmable controllers of the family c-pro 3.
The main features of the interface are the possibility to communicate to the user a great deal of information and the remarkable ease of
control; these features are due to the use of a 240 x 140 pixel single colour touch-screen LCD graphic display (black with rearlighting
through white LEDs), to the 6 buttons (with preset functions) membrane keyboard and to the CAN bus (for the connection to the
controllers).
This last also allows the use of the interface in multimaster networks.
Thanks to its constructive features, Vtouch offers several mounting typologies; this is possible:
- by panel, at the front of units, of machines for refrigeration or for air conditioning, of electrical panels and as well as in all those
applications where a frontal protection degree IP65 is required
- built-in by wall, in traditional box (like "506" by BTicino)
- by wall, on the support CPVW00 by EVCO (to order separately).
Also the necessity to customize the interface, in order to integrate it aesthetically in residential and commercial environments, is
satisfied by Vtouch since at the front of the interface one can apply both the plates CPVP* by EVCO (to order separately, made in
plastic material and available in two different colorations, white and black) and the numerous plates series "Living" and "Light" by
BTicino.
Vtouch also has got:
- real time clock
- alarm buzzer.
For further information consult the Hardware manual of Vtouch.
7.3.2. Summarizing table of the main features and available models
Vtouch
Power supply 24 VAC / 20... 40 VDC not isolated 12... 24 VAC / 15... 40 VDC isolated
Real time clock incorporated incorporated
Alarm buzzer incorporated incorporated
Display
240 x 140 pixel
touch-screen LCD graphic display
240 x 140 pixel
touch-screen LCD graphic display
Communication ports
a) CAN port with CANbus
communication protocol
b) programming port
2
a + b
2
a + b
Code EPV4TBR EPV3TBR
For further models please contact the EVCO’s sales network at the address [email protected].
