Networks / CAN
Bus
Baud - - - - - - - - - 20K
CANbus communication baud rate
20K = 20,000 baud
50K = 50,000 baud
125K = 125,000 baud
500K = 500,000 baud
Networks / CAN
Bus
Timeout 1 60 s 5
remote (or with a device in the network)
CANbus communication time-out (after this
time without CANbus communication with a
device, it is excluded by the network)
Networks / CAN
Bus
NetworkNode [ 1 ] 0
[ 32 ]
127
- - - [ 1 ] 99
address of a remote (or of a device in the
network) CAN node; example for [ 1 ] 2:
[ 1 ] = node
2 = node’s address
Networks / CAN
Bus
[ press button
RIGHT to
show it ]
TSEG1 0 15 - - - 10 reserved
Networks / CAN
Bus
[ press button
RIGHT to
show it ]
TSEG2 1 7 - - - 2 reserved
Networks / CAN
Bus
[ press button
RIGHT to
show it ]
SJW 0 3 - - - 0 reserved
Networks / CAN
Bus
[ press button
RIGHT to
show it ]
BTR(1) 1 255 - - - 100 reserved
Networks / CAN
Bus
[ press button
RIGHT to
show it ]
Status parameter available in read only modality
CAN machine status
INIT = initialization
STOPPED = CAN stop
OPERAT = operative
PRE-OP = in pre-operative
