EVCO S.p.A.
c-pro 3 micro and c-pro 3 kilo | Hardware manual ver. 1.0 | Code 114CP3UKE104
page 57 of 62
NTC analog inputs (10K
Ω @ 25 °C, 77 °F)
Kind of sensor:
β3435.
Working range:
from -50 to 120 °C (-58 to 248 °F).
Accuracy:
±0.5% of the full scale between -40 and 100 °C, ±1 °C
between -50 to -40 °C and between 100 and 120 °C.
Resolution: 0.1
°C.
Conversion time:
100 ms.
Protection: no
protection.
NTC analog inputs (10K
Ω @ 25 °C, 77 °F)
Kind of sensor:
NTC 2.
Working range:
from -40 to 86 °C (-40 to 186 °F).
Accuracy:
±1 °C.
Resolution: 0.1
°C.
Conversion time:
100 ms.
Protection: no
protection.
NTC analog inputs (10K
Ω @ 25 °C, 77 °F)
Kind of sensor:
NTC 3.
Working range:
from -40 to 86 °C (-40 to 186 °F).
Accuracy:
±1 °C.
Resolution: 0.1
°C.
Conversion time:
100 ms.
Protection: no
protection.
Pt 1000 analog inputs (1K
Ω @ 0 °C, 32 °F)
Working range:
from -100 to 400 °C (-148 to 752 °F).
Accuracy:
±0.5% of the full scale between -100 and 200 °C, ±2 °C
between 200 to 400 °C.
Resolution: 0.1
°C.
Conversion time:
100 ms.
Protection: no
protection.
0-20 mA / 4-20 mA analog inputs
Input resistance:
≤ to 200 Ω.
Accuracy:
±0.5% of the full scale.
Resolution: 0.01
mA.
Conversion time:
100 ms.
Protection:
no protection; the maximum current allowed on each input is
25
mA.
0-5 V ratiometric / 0-10 V analog inputs
Input resistance:
≥ to 10K Ω.
Accuracy:
±0.5% of the full scale.
Resolution: 0.01
V.
Conversion time:
100 ms.
Protection:
against the reversal of the polarity.
