EVCO S.p.A. c-pro 3 micro and c-pro 3 kilo | Hardware manual ver. 1.0 | Code 114CP3UKE104
page 58 of 62
Digital inputs:
According to the model:
• 5 optoisolated inputs at 24 VAC / DC of which 2 up to 2 KHz and 3 at 50 / 60 Hz in
c-pro 3 micro, c-pro 3 kilo, c-pro 3 EXP micro and c-pro 3 EXP kilo
• 9 optoisolated inputs at 24 VAC / DC of which 2 up to 2 KHz and 7 at 50 / 60 Hz in
c-pro 3 micro+, c-pro 3 kilo+, c-pro 3 EXP micro+ and c-pro 3 EXP kilo+
Optoisolated digital inputs at 24 VAC / DC
Power supply: 24 VAC (±15%), 50 / 60 Hz (±3 Hz) or 24 VDC (+66% -16%).
Input resistance: ≥ to 10K Ω.
Protection: no protection.
Displays:
c-pro 3 micro and c-pro 3
micro+
c-pro 3 kilo and c-pro 3
kilo+
I/O expansions
According to the model:
• 4 + 4 digits custom
display (with
function icons)
• nothing (blind
version).
According to the model:
• 128 x 64 pixel
single colour LCD
graphic display
(black with
rearlighting
through white
LEDs)
• 4 + 4 digits custom
display (with
function icons)
• nothing (blind
version).
Nothing (blind version).
Analog outputs:
3 non optoisolated outputs in c-pro 3 micro, c-pro 3 kilo, c-pro 3 EXP micro and c-pro 3
EXP kilo:
• 2 outputs configurable via configuration parameter for PWM / 0-10 V signal
• 1 output configurable via configuration parameter for 0-20 mA / 4-20 mA / 0-10 V
signal.
6 non optoisolated outputs in c-pro 3 micro+, c-pro 3 kilo+, c-pro 3 EXP micro+ and c-pro 3
EXP kilo+:
• 2 outputs configurable via configuration parameter for PWM / 0-10 V signal
• 2 outputs configurable via configuration parameter for 0-20 mA / 4-20 mA / 0-10 V
signal
• 2 outputs for 0-10 V signal.
PWM analog outputs
Driving power supply: 10 VDC (+16% -25%), 10 mA max.
Frequency: 0... 2 KHz.
Duty: 0... 100%.
Protection: no protection.
