EVCO S.p.A. c-pro 3 micro and c-pro 3 kilo | Hardware manual ver. 1.0 | Code 114CP3UKE104
page 15 of 62
4.3. Meaning of connectors
The following tables show the meaning of the connectors.
Digital outputs 1… 7
Electromechanical relays.
Terminal Meaning
NO6 normally open contact digital output 6 (3 res. A @ 250 VAC)
NO7 normally closed contact digital output 7 (3 res. A @ 250 VAC)
CO6/7 common digital outputs 6 and 7
Terminal Meaning
NO1 normally open contact digital output 1 (3 res. A @ 250 VAC)
NO2 normally open contact digital output 2 (3 res. A @ 250 VAC)
CO1/2 common digital outputs 1 and 2
NO3 normally open contact digital output 3 (3 res. A @ 250 VAC)
NO4 normally open contact digital output 4 (3 res. A @ 250 VAC)
NO5 normally open contact digital output 5 (3 res. A @ 250 VAC)
CO3/4/5 common digital outputs 3, 4 and 5
The maximum length of the connecting cables of the digital outputs is 100 m (328 ft).
Digital outputs 8 and 9
According to the model, electromechanical or solid state relays.
Terminal Meaning
CO8 common digital output 8
NO8
normally open contact digital output 8 (3 res. A @ 250 VAC in case of electromechanical relay; 24 VAC/DC, 0,6 A
max in case of solid state relay)
NC8 normally closed contact digital output 8
Terminal Meaning
CO9 common digital output 9
