7.5. Vcolor
7.5.1. Introduction
Vcolor is a new and innovative user interface for the programmable controllers of the family c-pro 3.
The main features of the interface are the possibility to communicate to the user a great deal of information and the remarkable ease of
control; these features are due to the use of a 320 x 240 pixel colour touch-screen TFT graphic display and to the CAN bus (for the
connection to the controllers).
This last also allows the use of the interface in multimaster networks.
Thanks to its constructive features, Vcolor offers several mounting typologies; this is possible:
- by panel, at the front of units, of machines for refrigeration or for air conditioning, of electrical panels and as well as in all those
applications where a frontal protection degree IP65 is required
- built-in by wall, in traditional box (like "506" by BTicino)
- by wall, on the support CPVW00 by EVCO (to order separately).
Also the necessity to customize the interface, in order to integrate it aesthetically in residential and commercial environments, is
satisfied by Vcolor since at the front of the interface one can apply both the plates CPVP* by EVCO (to order separately, made in
plastic material and available in two different colorations, white and black) and the numerous plates series "Living" and "Light" by
BTicino.
Vcolor also has got:
- real time clock
- alarm buzzer
- RS-485 communication port with Modbus communication protocol
- USB communication port.
For further information consult the Hardware manual of Vcolor.
7.5.2. Summarizing table of the main features and available models
Vcolor
Power supplì 24 VAC / 20... 40 VDC not isolated
Real time clock incorporated
Alarm buzzer incorporated
Display
320 x 240 pixel
touch-screen TFT graphic display
Communication ports
a) CAN port with CANbus
communication protocol
b) USB (for programming)
c) RS-485 with Modbus
communication protocol
3
a + b + c
Code EPV4CBR
For further models please contact the EVCO’s sales network at the address [email protected].
