EVCO S.p.A. c-pro 3 micro and c-pro 3 kilo | Hardware manual ver. 1.0 | Code 114CP3UKE104
page 59 of 62
0-20 mA / 4-20 mA analog outputs
Input resistance: 40... 300 Ω.
Accuracy: ±3% of the full scale.
Resolution: 0.05 mA.
Conversion time: 1 s.
Protection: no protection.
0-10 V analog outputs
Input resistance: 1K Ω.
Accuracy: +2% -5% of the full scale for users having impedance between
1 and 5K Ω, ±2% of the full scale for users having impedance
> of 5K Ω.
Resolution: 0.01 V.
Conversion time: 1 s.
Protection: no protection.
Digital outputs:
In c-pro 3 micro e c-pro 3 EXP micro:
• 6 SPST outputs (electromechanical relays) rated 3 res. A @ 250 VAC.
In c-pro 3 kilo and c-pro 3 EXP kilo:
• 7 SPST outputs (electromechanical relays) rated 3 res. A @ 250 VAC.
According to the model in c-pro 3 micro+ and c-pro 3 kilo+:
• 9 outputs (electromechanical relays) of which 7 SPST outputs rated 3 res. A @
250 VAC (K1... K7) and 2 SPDT outputs rated 3 res. A @ 250 VAC (K8 and K9)
• 9 outputs of which 7 SPST electromechanical relays rated 3 res. A @ 250 VAC
(K1... K7) and 2 solid state relays rated 24 VAC / DC, 0.6 A max. (K8 and K9)
• 7 SPST outputs (electromechanical relays) rated 3 res. A @ 250 VAC and an
unipolar stepper electronic expansion valves driver.
According to the model in c -pro 3 EXP micro+ and c-pro 3 EXP kilo+:
• 9 outputs (electromechanical relays) of which 7 SPST outputs rated 3 res. A @
250 VAC (K1... K7) and 2 SPDT outputs rated 3 res. A @ 250 VAC (K8 and K9)
• 9 outputs of which 7 SPST electromechanical relays rated 3 res. A @ 250 VAC
(K1... K7) and 2 solid state relays rated 24 VAC / DC, 0.6 A max. (K8 and K9).
The devices ensure a double isolation among each terminal of the digital outputs and the
remaining parts of the device.
Unipolar stepper electronic
expansion valves driver:
12 VDC, 260 mA max.
Type of actions and additional
features:
1B.
