RocketLinx ES8510 and ES8510-XT User Guide: 2000513 Rev. H Basic Settings - 45
Configuration Using the Web Interface
Basic Settings
The Basic Setting group allows you the ability to configure switch information, IP address, User name/
Password of the system. It also allows you to do firmware upgrade, backup and restore configuration, reload
factory default, and reboot the system.
The following web pages are included in this group:
• Switch Setting on Page 45
• Admin Password on Page 46
• IP Configuration on Page 47
• Time Setting on Page 49
• DHCP Server Configuration on Page 52
• DHCP Leased Entries on Page 54
• DHCP Relay Agent on Page 55
• Backup and Restore on Page 57
• Firmware Upgrade on Page 61
• Load Default on Page 63
• System Reboot on Page 64
Optionally, you can use the CLI for configuration, see Basic Settings (CLI) on Page 138.
Switch Setting
You can assign the System Name, Location, Contact and view ES8510 information.
Switch Setting Page
System Name
You can assign a name to the ES8510. You can input up to 64 characters. After you
configure the name, The CLI system selects the first 12 characters as the name in
CLI system.
System Location You can specify the ES8510 physical location with up to 64 characters.
System Contact
You can specify contact people with up to 64 characters by typing the Administer’s
name, mail address or other information.
System OID
The SNMP Object ID of the ES8510. You can follow the path to find its private MIB
in an MIB browser.
Note: When you attempt to view private MIB, you should first compile private MIB
files into your MIB browser.
System Description RocketLinx ES8510 Industrial Managed Ethernet Switch.
Firmware Version Displays the firmware version installed in this ES8510.
