40 - Feature Overview RocketLinx ES8510 and ES8510-XT User Guide: 2000513 Rev. H
Configuration Using the Web User Interface
MSTP Information
MSTP Information
on Page 80
• Instance ID
• Root Information
- Root Address
- Root Priority
- Root Port
- Root Path Cost
- Maximum Age
- Hello Time
- Forward Delay
• Port Information
- Role
- Port State
- Path Cost
- Port Priority
- Link Type
- Edge Port
MSTP Port
Configuration
MSTP Port
Configuration
on
Page 79
Instance ID
• Port
• Path Cost
• Priority
• Link Type
• Edge Port
Ping Utility
Ping Utility on
Page 121
Target IP Address
Port Control
Port Control on
Page 65
• Enable/Disable Port State
• Speed/Duplex - Auto-Negotiation, 10 Full/Half, 100 Full/
Half, and 1000 Full/Half (Ports 8-10)
• Flow control - Disable/Symmetric
• User-Defined Description
Port Mirror Mode
Port Mirroring on
Page 118
• Port Mirror Mode - Enable/Disable
• Port by Port
- Source Port - Rx and Tx
- Destination Port - Rx and Tx
Port Security
Port Security on
Page 104
• Port Security State - Port by Port
• Add Port Security Entry - Port, VID, and MAC Address
• Port Security Entry List - Port VID, and MAC Address
Type Category Details
