RocketLinx ES8510 and ES8510-XT User Guide: 2000513 Rev. H
Traffic Prioritization (CLI) - 165
Configuration Using the Command Line Interface (CLI)
CoS-Queue Mapping (cont.)
Display – CoS-Queue
mapping
Switch# sh qos cos-map
CoS to Queue Mapping :
CoS Queue
---- + ------
0 1
1 0
2 0
3 1
4 2
5 2
6 3
7 3
DSCP-Queue Mapping
Format
Switch(config)# qos dscp-map
PRIORITY Assign an priority (63 highest)
Switch(config)# qos dscp-map 0
QUEUE Assign an queue (0-3)
Format: qos dscp-map priority_value queue_value.
Map DSCP 0 to Queue 1
Switch(config)# qos dscp-map 0 1
The TOS/DSCP to queue mapping is set ok.
Display – DSCO-Queue
mapping
Switch# show qos dscp-map
DSCP to Queue Mapping : (dscp = d1 d2)
d2| 0 1 2 3 4 5 6 7 8 9
d1 |
-----+----------------------
0 | 1 1 1 1 1 1 1 1 0 0
1 | 0 0 0 0 0 0 0 0 0 0
2 | 0 0 0 0 1 1 1 1 1 1
3 | 1 1 2 2 2 2 2 2 2 2
4 | 2 2 2 2 2 2 2 2 3 3
5 | 3 3 3 3 3 3 3 3 3 3
6 | 3 3 3 3
