Brother FAX-2000P - Manual (Page 43)

Operation Panel
►
'“a
13
1------ 1
14
1------ 1 ------ 1 ^^1------ 1
19
i------- 1
20
1------ 1
21
1~~1
22 23
rrzi
24
i------- 1
H >
PI 1^ P2|____ 1 P 3 1 1 P 4 ^ __ 1 P 5 ^ __ 1 P 6 , __ ,
1 ___1
§
©RESOLUTION/SELECT Key
Press this key to change the resolution. Press
this key while in the setting mode to call up an
item following the currently displayed item.
© -i>-Key
Press this key to enter a dash (-) while
programming a facsimile number.
Press this key to move the cursor to the right
while in the data entry mode.
©CONTRAST/CANCEL Key
Press this key to change the scanning density.
Press this key while in the setting the operation
mode to cancel the data currently displayed.
© ^ ABBR Key
Press this key first to perform abbreviated
dialing.
Press this key while in the mode for character
entry to scroll down the character group.
©Numeric Keypad
Twelve-key set used to dial or store a facsimile
number. Also, press these keys after pressing
the FUNCTION key to specify the operation
mode.
©START Key
Press this key to begin communication.
©One-touch Program Keys (P1-P6)
Used for programming one-touch dialing or
communication mode.
©One-touch Keys (01-24)
Press this key to start one-touch dialing.
©STOP Key
Press this key to manually terminate
transmission, reception, copying and mode
setting operations.
©COPY Key
Press this key to begin copying the document
placed on the ADR
Press this key to print out various llsts/reports
manually.
©AUTO RECEIVE Lamp
Lights when the FAX-2000P is in the automatic
reception mode (Fax Ready, Tel/Fax Ready or
Ans/Fax Ready).
©CONFIRM REPORT Lamp
Indicates that the transmission (or reception)
confirmation report is to be printed out.
©ON HOOK Lamp
Lights when dialing a facsimile/telephone
number after pressing the DIAL key.
©HOLD Lamp
Indicates that a telephone call is being placed
on hold.
©ERROR Lamp
Indicates occurrence of an error.
©LCD Display
Indicates the operating status.
31
