KEYENCE DL-EP1 User Manual

Page 87

3-4 Message Communication

3-57

om
m

uni

tin

ith

- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (IB) -

*2 To execute measured correction, set the calibration function (036BH(875)) to "1.

Measured correction".
When executing measured correction, set measured correction 1st-point target
value (036CH(876)) and measured correction 2nd-point target value036DH(877))
and then execute the measured correction execution request (operation
command, 0313H(787)), 0314H788.

*3 To execute measured correction, set the calibration function (036BH(875)) to "2.

Measured correction".
When executing logical correction, set logical correction 1st target value
(036CH(876)), logical correction 2nd target value (036DH(877)), logical
correction 1st measurement value (0373H(883)), and logical correction 2nd
measurement value (0374H(884)) and then execute the logical correction
execution request (operation command (031AH(794), 031BH(795)).

*4 Executing other settings in the middle of the 1st- or 2nd-point target or

measurement value makes it impossible to complete calibration setting. Be sure
to set the 1st- and 2nd-point target or measurement values continuously.

• Commands

031AH

(794)

Logical correction 1st req

(SET1 confirmation

operation)

Executes logical correction.

Set the R.V. value that you want to correct in the attribute

for IB Series "logical correction 1st point measurement

value" or "logical correction 2nd point measurement

value".

Set the R.V. value that you want to display in the attribute

for the IB Series "Measured Correction/Logical Correction

1st Point Target Value" or "Measured Correction/

Theoretical Correction 2nd Point Target Value".

For details on the measured correction execution

procedure, refer to "IB Series User's Manual".

*3, *4

031BH

(795)

Logical correction 2nd req

(SET2 confirmation

operation)

Item

Description

Data Example

Service Code

Designates the "operation command (4BH)" (fixed

value).

4BH

Class ID

Designates DL Object (67H)(fixed value).

67H

Instance ID

Designates the ID number. The ID number (00H) of the

DL-EP1 cannot be designated.

08H

Attribute ID

Designates the attribute ID to be designated from

"Attribute".

"(3) Issuing operation commands to a

sensor amplifier" "Attribute IDs supported by the

instance service 4BH (operation command)" (Page 3-

55)

0301H(769)

Service Data

There is no service response data.

Attribute

Name

Description
