3-3 Cyclic communication
3-16
3
C
om
m
uni
ca
tin
g
w
ith
IB
S
er
ie
s
The data to the sensor amplifier is assigned to the OUT area of the EtherNet/IP
scanner.
„ External Input (5 Words (10 Bytes)) assembly instance (Instance ID): 65H
ID numbers (ID01 to ID04) are assigned for each sensor amplifier according to the
number of sensor amplifiers. The ID numbers larger than the number of connected
sensor amplifiers and ID05 to ID15 are not assigned.
* External inputs 1 to 4 are assigned any function and used. For details on the
functions to be assigned, refer to "IB User's Manual".
Assignment to OUT Area (Scanner to DL-EP1)
DL-EP1 data
Scanner's OUT area
Address 0
Address 1
Address 9
External Input
(Assembly Instance: 101)
1-byte (8-bit) data
Name
Address
(Byte)
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
External
Input
Request 1
(External
Input 1)
0 ID08 . . . . . ID01
1
Reserved for
system
ID15 . . . . . ID09
External
Input
Request 2
(External
Input 2)
2 ID08 . . . . . ID01
3
Reserved for
system
ID15 . . . . . ID09
External
Input
Request 3
(External
Input 3)
4 ID08 . . . . . ID01
5
Reserved for
system
ID15 . . . . . ID09
External
Input
Request 4
(External
Input 4)
6 ID08 . . . . . ID01
7
Reserved for
system
ID15 . . . . . ID09
External
Input
Request 5
(Unassigned)
8 ID08 . . . . . ID01
9
Reserved for
system
ID15 . . . . . ID09
