3-4 Message Communication
3-43
3
C
om
m
uni
ca
tin
g
w
ith
IB
S
er
ie
s
- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (IB) -
Group2
034AH
(842)
HIGH setting
value
(BANK 3)
Sets the HIGH setting value (BANK 3).
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 20.00)
When measurement mode is dimension mode:
-99.999 to +99.999 (initial value: 2,000)
R/W DINT
034BH
(843)
LOW setting
value
(BANK 3)
Sets the LOW setting value (BANK 3).
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 10.00)
When measurement mode is dimension mode:
-99.999 to +99.999 (initial value: 1,000)
R/W DINT
034CH
(844)
Shift
target value
(BANK 3)
Sets the shift target value (BANK 3).
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 0.00)
When measurement mode is dimension mode:
-99.999 to +99.999 (initial value: 0.000)
R/W DINT
034DH
(845) to
035FH
(863)
(Reserved for system)
Group3
0360H
(864)
Group3 Entry
count
Indicates the group 3 entry count.
Parameter range: 20
R DINT
0361H
(865)
Key lock setting
Sets key lock.
Parameter range: 0 to 1 (initial value: 0)
0: Unlock
1: Key lock
R/W DINT
0362H
(866)
Bank setting
Reads the current attribute.
Check the number of the bank where the sensor
amplifier is operating from the bank status
(032BH811)).
Parameter range: 0 to 3
R DINT
Changes the operating bank.
To change the bank number using this attribute, set
"bank switching method (0396H(918))" to "button".
For "external input", this attribute is invalid.
Parameter range: 0 to 3
0: Rewrites the operating bank with bank 0.
1: Rewrites the operating bank with bank 1.
2: Rewrites the operating bank with bank 2.
3: Rewrites the operating bank with bank 3.
W DINT
0363H
(867)
Timing input *9
Sets the timing input.
Check the timing input status of the operating
sensor amplifier according to the timing status
(032CH(812)).
The sensor amplifier operates based on OR of
the external input line and cyclic communication.
Parameter range: 0 to 1 (initial value: 0)
0: Timing input OFF
1: Timing input ON
R/W DINT
Class
Attribute
ID
Name Description Attribute
Data
Type
