3-4 Message Communication
3-36
3
C
om
m
uni
ca
tin
g
w
ith
IB
S
er
ie
s
00H
91H
(145)
to 92H
(146)
:
93H
(147)
Current
Value 0 (ID
Number 4)
Indicates the current value 0 of the sensor of ID
number 4.
Parameter range:
-2147483648 to 2147483647
R WORD
94H
(148)
to 9EH
(158)
Current
Value 0 (ID
Number 5) to
(ID Number
15)
(Unassigned) R DINT
9FH
(159)
Reserved for system
A0H
(160)
to AEH
(174)
Current
Value 1 (ID
Number 1) to
(ID Number
15)
(Unassigned) R DINT
AFH
(175)
Reserved for system
B0H
(176)
Sensor
Status Mask
Setting
Set up the condition to determine if the sensor
error or warning is a recoverable DL-EP1 error
(MS LED blinks in red). If mask is selected, MS
LED does not blink in red when a sensor error or
warning occurs.
Parameter range: 0 to 1 (initial value: 0)
0: Not mask
1: Mask
R/W UINT
B1H
(177)
Sensor
Connected
Number
Indicates the number of connected sensor
amplifiers.
Parameter range: 0 to 4
R UINT
B2H
(178)
to C7H
(199)
Reserved for system
0300H
(768)
Error Code
(ID number
0)
Indicates the error code of ID number 0.
Parameter range: 0 to 65535
R UINT
0301H
(769)
to
0303H
(771)
:
0304H
(772)
Error Code
(ID number
4)
Indicates the error code of ID number 4.
Parameter range: 0 to 65535
R UINT
Instance
ID
Attribute
ID
Name Description Attribute
Data
Type
