- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (IB) -
3-4 Message Communication
3-34
3
C
om
m
uni
ca
tin
g
w
ith
IB
S
er
ie
s
Attributes
Instance
ID
Attribute
ID
Name
Description
Attribute
Data
Type
00H
64H
(100)
Status
Indicates the status of this unit and connected
sensor amplifier.
Bit0: DL-EP1 Error Status
Bit 1 to bit 13: Reserved for system
Bit14: Warning Status
Bit15: Error Status
R
WORD
65H
(101)
Sensor Error
Status
Indicates the error status of the connected
sensor amplifiers. If an error occurs, the bit of the
corresponding ID number of amplifier is turned
to ON.
Bit 0 to bit 3: ID number 1 to ID number 4
Bit 4 to bit 15: Reserved for system
R
WORD
66H
(102)
Warning
Status
Indicates the warning status of each sensor
amplifier. If a warning occurs, the bit
corresponding to the ID number of the sensor
amplifier is set to ON.
Bit 0 to bit 3: ID number 1 to ID number 4
Bit 4 to bit 15: Reserved for system
R
WORD
67H
(103)
Reserved for system
68H
(104)
Current
Value 0
Property
Indicates the status of current value 0 of each
amplifier. If the current value 0 is “Over Range",
“Under Range", or "Invalid", the bit
corresponding to the ID number is turned ON.
Bit 0 to bit 3: ID number 1 to ID number 4
Bit 4 to bit 15: Reserved for system
R
WORD
69H
(105)
Current
Value 1
Property
(Unassigned)
R
WORD
6AH
(106) to
6BH
(107)
Reserved for system
6CH
(108)
Error ID
Number
Indicates the ID number of the unit having error.
Parameter range: 0 to 4
R
UINT
6DH
(109)
Error Code
Indicates the error code that is happening.
Parameter range: 0 to 65535
R
UINT
6EH
(110)
Warning ID
Number
Indicates the ID number of the device where the
warning occurred.
Parameter range: 0 to 4
R
UINT
6FH
(111)
Warning
Code
Indicates the warning code that has occurred.
Parameter range: 0 to 65535
R
UINT
70H
(112) to
73H
(115)
Reserved for system
74H
(116)
Output1
(HIGH)
Indicates the HIGH output (output 1) status of
each amplifier. When HIGH is output, the bit
corresponding to the ID number of the sensor
amplifier is turned ON.
Bit 0 to bit 3: ID number 1 to ID number 4
Bit 4 to bit 15: Reserved for system
R
WORD
