- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (IB) -
3-4 Message Communication
3-46
3
C
om
m
uni
ca
tin
g
w
ith
IB
S
er
ie
s
Group4
0385H
(901)
Averaging/
High-pass
filter
Sets the averaging/high-path filter.
Parameter range: 0 to 19 (initial value: 5)
0 : 1 times
1 : Twice
2 : 4 times
3 : 8 times
4 : 16 times
5 : 64 times
6 : 256 times
7 : 1024 times
8 : 4096 times
9 : 16384 times
10 : 0.1Hz
11 : 0.2Hz
12 : 0.5Hz
13 : 1Hz
14 : 2Hz
15 : 5Hz
16 : 10Hz
17 : 20Hz
18 : 50Hz
19 : 100Hz
R/W DINT
0386H
(902)
Output mode
Sets output mode.
Parameter range: 0 to 1 (initial value: 0)
0: N.O.
1: N.C.
R/W DINT
0387H
(903)
(Reserved for system)
0388H
(904)
Hold
function
setting
Sets the hold function.
Parameter range: 0 to 5 (initial value: 0)
0: Sample hold
1: Peak hold
2: Bottom hold
3: Peak-to-peak hold
4: Auto peak hold
5: Auto bottom hold
R/W DINT
0389H
(905)
Auto hold
trigger level
Sets the auto peak hold trigger level or auto
bottom hold trigger level.
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 90.00)
When measurement mode is dimension mode:
-99.999 to +99.999 (initial value: 9,000)
R/W DINT
038AH
(906)
Timing input
setting
Sets the timing input.
Parameter range: 0 to 1 (initial value: 0)
0: Level
1: Edge
R/W DINT
038BH
(907)
Delay timer
Sets the delay timer.
Parameter range: 0 to 3 (initial value: 0)
0: OFF
1: On delay
2: Off delay
3: One shot
R/W DINT
Class
Attribute
ID
Name Description Attribute
Data
Type
