3-4 Message Communication
3-45
3
C
om
m
uni
ca
tin
g
w
ith
IB
S
er
ie
s
- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (IB) -
Group3
036CH
(876)
Meas./Logical
correct
target 1
*10, *11, *12
Sets the 1st-point target value of the measured
correction or logical correction.
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 0.00)
When measurement mode is dimension mode:
-99.999 to +99.999 (measured correction only)
(initial value: 0.000)
R/W DINT
036DH
(877)
Meas./Logical
correct
target 2
*10, *11, *12
Sets the 2nd-point target value of the measured
correction or logical correction.
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 100.00)
When measurement mode is dimension mode:
-99.999 to +99.999 (measured correction only)
(initial value: 10.000)
R/W DINT
036EH
(878) to
0372H
(882)
(Reserved for system)
0373H
(883)
Logical
correction
measured 1
*11, *12
Sets the logical correction 1st-point
measurement value.
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 0.00)
When measurement mode is dimension mode:
Unusable
R/W DINT
0374H
(884)
Logical
correction
measured 2
*11, *12
Sets the logical correction 2nd-point
measurement value.
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 100.00)
When measurement mode is dimension mode:
Unusable
R/W DINT
0375H
(885) to
037FH
(895)
(Reserved for system)
Group4
0380H
(896)
Group4
Entry count
Indicates the group 4 entry count.
Parameter range: 30
R DINT
0381H
(897)
(Reserved for system)
0382H
(898)
Measurement
mode 15
Sets measurement mode.
Parameter range: 0 to 1 (initial value: 0)
0: % mode
1: Dimension mode
R/W DINT
0383H
(899)
Received/
Blocked light
mode
Sets light entrance/light shading amount mode.
Parameter range: 0 to 1 (initial value: 0)
0: Light entrance amount display
1: Light shading amount display
R/W DINT
0384H
(900)
(Reserved for system)
Class
Attribute
ID
Name Description Attribute
Data
Type
