3-4 Message Communication
3-41
3
C
om
m
uni
ca
tin
g
w
ith
IB
S
er
ie
s
- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (IB) -
Group1
0338H
(824)
System
parameter
current
state *6
Reads the system parameter current state.
Check the system parameter of the actually
operating amplifier from this attribute.
The bit corresponding to the current state is set
to ON.
Bit0:
0:NPN
1:PNP
Bits 1 to 3 (main unit only. The expansion unit is
fixed at 000.)
000: OFF
001: 0 to 5 V
010: -5 to 5 V
011: 1 to 5 V
100: 4 to 20 mA
R DINT
0339H
(825)
(Reserved for system)
033AH
(826)
Ref. light
registration
result
Reads the Ref. light registration result.
Parameter range: 0 to 3
0: Ref. light registration now in progress
1: Normal end
2: Insufficient light reception error
3: Interfering light error
R DINT
033BH
(827)
Adjust result
Reads the adjust/adjust reset execution result.
Parameter range: 0 to 4
0: Adjust/adjust reset execution now in progress
1: Normal end
2: Insufficient light quantity error
3: Interfering light error
4: Light quantity excess error
R DINT
033CH
(828)
Tuning
result *7
Reads the execution result of tolerance/two-point
tuning.
Parameter range: 0 to 2
0: Tolerance/two-point tuning execution now in
progress
1: Normal end
2: Abnormal end
R DINT
033DH
(829)
Correction
result
*8
Reads the execution result of measured
correction/theoretical correction.
Parameter range: 0 to 2
0: Measured correction/theoretical correction
execution now in progress
1: Normal end
2: Abnormal end
R DINT
033EH
(830) to
033FH
(831)
(Reserved for system)
Class
Attribute
ID
Name Description Attribute
Data
Type
