- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (IB) -
3-4 Message Communication
3-44
3
C
om
m
uni
ca
tin
g
w
ith
IB
S
er
ie
s
Group3
0364H
(868)
Laser
emission
stop input *9
Sets the laser emission stop input status.
Check the emission stop input status of the
operating sensor amplifier from the transmission
stop status (0332H(818)).
The sensor amplifier operates based on OR of
the external input line and cyclic communication.
Parameter range: 0 to 1 (initial value: 0)
0: Emission stop input OFF
1: Emission stop input ON
R/W DINT
0365H
(869) to
0367H
(871)
(Reserved for system)
0368H
(872)
Sub display's
screen
Sets the sub display's screen.
Parameter range: 0 to 4 (initial value: 0)
0: r.v value
1: Analog value
2: HI setting value
3: LO setting value
4: Zero shift value
R/W DINT
0369H
(873)
System
parameter *6
Sets the system parameter.
Reflecting the system parameter setting requires
"system parameter set execution request
(0306H(774)) of the operation command after the
setting is written.
Check the system parameter of the operating
sensor amplifier from 0338(H824).
Bit0:
0:NPN
1:PNP
Bits 1 to 3 (main unit only. The expansion unit is
fixed at 000.)
000: OFF
001: 0 to 5 V
010: 5 to 5 V
011: -1 to 5 V
100: 4 to 20 mA
R/W DINT
036AH
(874)
Tol. tuning
setting width
Sets the tolerance setting width.
When measurement mode is % mode:
0.00 to 999.99 (initial value: 10.00)
When measurement mode is dimension mode:
0.000 to 99.999 (initial value: 1,000)
R/W DINT
036BH
(875)
Calibration
function
*10, *11
Sets the correction method.
Parameter range: 0 to 2 (initial value: 0)
0: No correction
1: Measured correction
2: Theoretical correction (% mode only)
R/W DINT
Class
Attribute
ID
Name Description Attribute
Data
Type
