- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (IB) -
3-4 Message Communication
3-42
3
C
om
m
uni
ca
tin
g
w
ith
IB
S
er
ie
s
Group2
0340H
(832)
Group2 Entry
count
Indicates the group 2 entry count.
Parameter range: 12
R DINT
0341H
(833)
HIGH setting
value
(BANK 0)
Sets the HIGH setting value (BANK 0).
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 20.00)
When measurement mode is dimension mode:
-99.999 to +99.999 (initial value: 2,000)
R/W DINT
0342H
(834)
LOW setting
value
(BANK 0)
Sets the LOW setting value (BANK 0).
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 10.00)
When measurement mode is dimension mode:
-99.999 to +99.999 (initial value: 1,000)
R/W DINT
0343H
(835)
Shift
target value
(BANK 0)
Sets the shift target value (BANK 0).
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 0.00)
When measurement mode is dimension mode:
-99.999 to +99.999 (initial value: 0.000)
R/W DINT
0344H
(836)
HIGH setting
value
(BANK 1)
Sets the HIGH setting value (BANK 1).
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 20.00)
When measurement mode is dimension mode:
-99.999 to +99.999 (initial value: 2,000)
R/W DINT
0345H
(837)
LOW setting
value
(BANK 1)
Sets the LOW setting value (BANK 1).
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 10.00)
When measurement mode is dimension mode:
-99.999 to +99.999 (initial value: 1,000)
R/W DINT
0346H
(838)
Shift
target value
(BANK 1)
Sets the shift target value (BANK 1).
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 0.00)
When measurement mode is dimension mode:
-99.999 to +99.999 (initial value: 0.000)
R/W DINT
0347H
(839)
HIGH setting
value
(BANK 2)
Sets the HIGH setting value (BANK 2).
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 20.00)
When measurement mode is dimension mode:
-99.999 to +99.999 (initial value: 2,000)
R/W DINT
0348H
(840)
LOW setting
value
(BANK 2)
Sets the LOW setting value (BANK 2).
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 10.00)
When measurement mode is dimension mode:
-99.999 to +99.999 (initial value: 1,000)
R/W DINT
0349H
(841)
Shift
target value
(BANK 2)
Sets the shift target value (BANK 2).
When measurement mode is % mode:
-999.99 to +999.99 (initial value: 0.00)
When measurement mode is dimension mode:
-99.999 to +99.999 (initial value: 0.000)
R/W DINT
Class
Attribute
ID
Name Description Attribute
Data
Type
