- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (IB) -
3-4 Message Communication
3-50
3
C
om
m
uni
ca
tin
g
w
ith
IB
S
er
ie
s
*1 You can check the error contents of the sensor amplifier according to the
ON/OFF status of each bit.
OFF(0): No error occurred. ON(1): An error occurred.
Two or more errors may simultaneously occur. For details on each error, refer
to "IB Series User's Manual".
Group6
03C0H
(960)
Group6 Entry
count
Indicates the group 6 entry count.
Parameter range: 11
R DINT
03C1H
(961)
Product code
Indicates the product code.
Main unit: 4020
Expansion unit: 4021
R DINT
03C2H
(962)
Revision
Indicates the revision.
Parameter range: 0101H
R DINT
03C3H
(963)
Transmission
Side
Head Model
Indicates the model of the head connected to the
sensor head connector (transmission side).
Parameter range: 0 to 4
0: No head is connected or the R head is
connected.
1: IB-01
2: IB-05
3: IB-10
4: IB-30
R DINT
03C4H
(964)
Light
Receiving
Side
Head Model
Indicates the model of the head connected to the
sensor head connector (light receiving side).
Parameter range: 0 to 4
0: No head is connected or the T head is
connected.
1: IB-01
2: IB-05
3: IB-10
4: IB-30
R DINT
03C5H
(965) to
03C7H
(967)
(Reserved for system)
03C8H
(968)
Product
name
Indicates the sensor product name.
Main unit: "IB-1000/1500"
Expansion unit: "IB-1050/1550"
R STRING
03C9H
(969) to
03D6H
(982)
(Reserved for system)
03D7H
(983)
Series code
Indicates the series code.
Main unit: 4020
Expansion unit: 4021
R DINT
03D8H
(984)
Series
version
Indicates the series version.
Parameter range: 1
R DINT
03D9H
(985)
Device type
Indicates the device type.
Parameter range: 0
R DINT
03DAH
(986) to
03DFH
(991)
(Reserved for system)
Class
Attribute
ID
Name Description Attribute
Data
Type
