3-4 Message Communication
3-49
3
C
om
m
uni
ca
tin
g
w
ith
IB
S
er
ie
s
- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (IB) -
Group4
039DH
(925)
Judgment
indicator
color
Sets the display colors of judgement output
indicators.
Parameter range: 0 to 3 (initial value: 0)
0: Only GO is green (initial status)
1: Only GO is red
2: All P.V. values are green
3: All P.V. values are red
R/W DINT
039EH
(926)
P.V. value
display color
Sets P.V. value display colors.
Parameter range: 0 to 3 (initial value: 0)
0: Green when GO (initial status)
1: Red when GO
2: All P.V. values are green
3: All P.V. values are red
R/W DINT
039FH
(927)
(Reserved for system)
Group5
03A0H
(928)
Group5
Entry count
Indicates the group 5 entry count.
Parameter range: 9
R DINT
03A1H
(929)
Save adjust
state
Sets whether to store the adjust status.
Parameter range: 0 to 1 (initial value: 0)
0:OFF
1:ON
R/W DINT
03A2H
(930)
Adjust level
Sets an adjust level.
Parameter range: 1 to 30 (initial value: 20)
R/W DINT
03A3H
(931)
Auto
adjust
function
Sets whether to enable the auto adjust function.
Parameter range: 0 to 1 (initial value: 0)
0: Disable
1: Enable
R/W DINT
03A4H
(932)
Auto
adjust level
Sets an auto adjust level.
0.50 to 20.00 (initial value: 3.00)
R/W DINT
03A5H
(933)
Check output
function
Sets whether to enable the check output
function.
Parameter range: 0 to 1 (initial value: 0)
0: OFF
1: ON
R/W DINT
03A6H
(934)
Check output
light level
Sets the light quantity level of the check output
function.
Parameter range: 1 to 30 (initial value: 10)
R/W DINT
03A7H
(935)
Error output
mode
Sets error output mode.
Parameter range: 0 to 1 (initial value: 0)
0: Normal mode (initial status)
1: Compatibility mode
R/W DINT
03A8H
(936)
Hysteresis
for trigger
level
Sets the trigger level hysteresis.
Parameter range: 0 to 1 (initial value: 0)
0: Initial state
1: User setting
R/W DINT
03A9H
(937)
Hys. set
value for
trigger level
Sets the hysteresis setting value for trigger level.
When measurement mode is % mode:
0.00 to 999.99 (initial value: 1.00)
When measurement mode is dimension mode:
0.000 to 99.999 (initial value: 0.100)
R/W DINT
03AAH
(938) to
03BFH
(959)
(Reserved for system)
Class
Attribute
ID
Name Description Attribute
Data
Type
