- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (IB) -

3-4 Message Communication

3-56

om
m

uni

tin

ith

0305H

(773)

Initial reset request

Initializes all the settings other than the calibration, ref.

light quantity registration, and system parameters of the

sensor amplifier.

All parameters are stored in nonvolatile memory

(EEPROM) approx. 3 minutes after the initial reset

request is executed. After the initial reset request has

been executed, "EEPROM write result" of the attribute for

IB Series becomes normal end (1).

0306H

(774)

System parameter set request

Changes the contents of the system parameter (settings of

judgement output, check output polarity, and analog output)

to the contents written in "system parameter" of the attribute

for the IB Series.

When executing the system parameter set, change the

contents tailored to the connected devices and wiring. If

the contents are changed by mistake, the devices

connected to the sensor amplifier may go down.

030AH

(778)

Ref. light registration request

Registers the ref. light quantity.

030BH

(779)

Adjust request

Executes the adjust function.

Turning off the sensor amplifier after executing the adjust

function restores the state before the adjust function is

executed. If the adjust value is retained even after the

sensor amplifier is turned off, set the adjust status storage

function to ON.

030CH

(780)

Adjust reset request

Initializes the adjust value.

030EH

(782)

Tolerance tuning request

Executes tolerance tuning.

Set the tolerance setting width using the attribute for IB

Series "tolerance setting width".

030FH

(783)

2-point tuning HIGH side 1st

req

Executes 2-point tuning.

For details on the two-point tuning execution procedure,

refer to "IB Series User's Manual".

0310H

(784)

2-point tuning HIGH side

2nd req (Determine HIGH

setting value.)

0311H

(785)

2-point tuning LOW side 1st

req

0312H

(786)

2-point tuning LOW side

2nd req

(Determine LOW setting

value)

0313H

(787)

Measured correction 1st

req

(SET1 confirmation

operation)

Executes measured correction.

Set the R.V. value that you want to display in the attribute

for the IB Series "Measured Correction/Theoretical

Correction 1st Point Target Value" or "Measured

Correction/Theoretical Correction 2nd Point Target Value".

For details on the measured correction execution

procedure, refer to "IB Series User's Manual".

*2, *4

0314H

(788)

Measured correction 2nd

req

(SET2 confirmation

operation)

Attribute

Name

Description
