Kontron CG1200 Carrier Grade Server Installation and Maintenance Guide 2
Appendix D: Getting Help
1.3 What Your Server Includes
Your CG1200 server includes the following components:
•
One 1U chassis
•
One Intel® Server Board S2400EP4 with DDR3 memory slots (memory not included)
•
Four removable hard drive carriers
•
One DC or AC power subsystem: one hot-swappable power supply module and a power distribution
board. (The other power supply bay has a filler panel in it. For redundancy another separately
orderable power supply module must be added.)
•
Five dual-rotor fan assemblies for cooling the processor(s), DIMM(s), PCI slot, and other internal
components in two cooling zones.
•
A front panel board ,LED/switch board, telco alarms module (TAM) board, and PCIe riser assembly
(for one FH/FL card)
•
Internal cables and connectors
See Chapter 3 for initial installation and configuration instructions.
1.4 Product Accessories
The following list shows the separately orderable components and optional accessories available for
inclusion in the initial order or to have as spares. Refer to the CG1200 Carrier Grade Server Configuration
Guide for a complete list of orderable spares and options. The Configuration Guide can be found on the
Kontron Support Website at
http://us.kontron.com/support/ (search for CG1200, click on Product
Downloads, then Ordering Guide).
•
LGA 2011 (socket R) support for Intel® Xeon® E5-2400 and E5-2400 v2 processors series
•
Registered DDR3 Memory (RDIMM), LV-RDIMM, Unbuffered DDR3 Memory (UDIMM) with ECC and
Load Reduced DDR3 Memory (LR-DIMM)
•
Up to four hot-swappable 2.5” SAS HDDs or SATA SSDs
•
Hard disk drive carriers (four already shipped with the server)
•
Optional Intel HW RAID on chip (ROC) or SW RAID IOC available.
•
Optional I/O module
•
Intel ® Remote Management Module 4 (RMM4) or RMM4Lite options
•
One front-access SD media flash module
•
Internal flash storage supported (eUSB)
•
Power cord
•
AC or DC power supply module (650W) for redundancy
•
Rack mount kits available for purchase directly from Kontron – see Configuration Guide
For information about the accessories, memory, processors, and ordering information, refer to the
CG1200 Carrier Grade Server Configuration Guide on
http://us.kontron.com/support/ (search for CG1200,
click on Product Downloads, then Ordering Guide).
For information about third-party hardware that has been tested and can be used with your system, refer
to the CG1200 Carrier Grade Server Tested Hardware and Operating System List (THOL) on
http://us.kontron.com/support/ (search for CG1200, click on Product Downloads, then Compatibility
Matrix).
