Kontron CG1200 Carrier Grade Server Installation and Maintenance Guide 5
Table 1: CG1200 Server Features
Feature Description
Peripheral Interfaces
External connections:
One DE-15 video VGA connector (rear)
One DB-15 TAM dry relay connector (rear)
Four RJ45 10/100/1000 Mbps network connections (rear)
Two USB 2.0 connectors (rear)
Two USB 2.0 connectors (front)
One RJ-45 serial connector (rear)
One dedicated management NIC port, (optional Intel® RMM4) or
personality module connector
Internal connections:
One internal USB header for embedded flash drives
One Intel® RAID C600 upgrade key connector with RKSAS54 pre-
installed
One RMM4 connector for an optional Intel® Remote Management Module
4 module
Video Integrated graphics core with 2D hardware accelerator
LAN Four RJ-45 10/100/1000 Mbps connectors
Expansion Capabilities One PCIe x16 Gen 3 riser slot
Hard Drive Options
Up to four 2.5-inch SAS HDD or SATA SDD hard drives
Onboard SAS SW RAID with Intel® ESRT2 RAID 0/1/10 or RSTe RAID
0/1/10
Intel® RAID on Chip (ROC) and I/O controller (IOC) support optional
Peripherals One SD media flash module (front panel access)
Front Panel Buttons
Power on/off
System reset
Chassis ID
NMI
Front Panel LEDs
Power status
Chassis identification
System status
HDD activity/fault
NIC activity
Alarms (critical, major, minor, power)
Power Supply
Up to two 650W power supply modules (AC or DC)
PMBus 1.2 specification support
Auxiliary I/O power dongle
Fans
Five 40x56mm dual rotor fans
Redundant cooling
System Management Integrated BMC (iBMC) with advanced options
