70 www.kontron.com
User’s Guide
TI Cortex A8 CPU
ULP-COM sA3874i Edge
finger
Net name Notes
C_A[24]/GP1[25] CAN0_ERR# to input
Alternate Function:
CAN0 bus error signal
R26 TIM4_IO/GP1[27] P117
GPIO9/
CAN1_ERR#
GPIO9/ CAN1_ERR#
Default Function :
Boot code should set this
to input
Alternate Function:
CAN1 bus error signal
M26
GPMC_ADV_ALE#/
GPMC_CS[6]#/TIM
5_IO/GP1[28]
P118 GPIO10 GPIO10
Default Function :
Boot code should set this
to input
Alternate Function:
General purpose IO
W28
EDMA_EVT0/GP1[3
1]
P119 GPIO11 GPIO11
Default Function :
Boot code should set this
to input
Alternate Function:
General purpose IO
AA10
VOUT[0]_AVID/VO
UT[0]_FLD
S120 LCD_DE VOUT_AVID
LCD data enable option
signal
T2 TCLKIN/GP0[30] S146 PCIE_WAKE# ARM_GPIO1
PCIe wake interrupt signal
through MAX V CPLD
L8 IO_L8/DEV_OE P75 PCIE_A_RST# PCIE_A_RST#
PCIe A optional active low
reset
L9 IO_L9 S54 SATA_ACT# SATA_ACT# SATA activity indicator
