User’s Guide
ULP-COM sA3874i Edge finger TI Cortex A8 CPU Notes
S100 LCD_D7 AG15 VOUT[0]_B_CB_C[9]
S101 GND42
S102 LCD_D8 AH7 VOUT[0]_G_Y_YC[2]
S103 LCD_D9 AH15 VOUT[0]_G_Y_YC[3]
S104 LCD_D10 AB8 VOUT[0]_G_Y_YC[4]
S105 LCD_D11 AB12 VOUT[0]_G_Y_YC[5]
S106 LCD_D12 AA8 VOUT[0]_G_Y_YC[6]
S107 LCD_D13 AD14 VOUT[0]_G_Y_YC[7]
S108 LCD_D14 AE14 VOUT[0]_G_Y_YC[8]
S109 LCD_D15 AF14 VOUT[0]_G_Y_YC[9]
S110 GND43
S111 LCD_D16 AD9 VOUT[0]_R_CR[2]
S112 LCD_D17 AB9 VOUT[0]_R_CR[3]
S113 LCD_D18 AA9 VOUT[0]_R_CR[4]
S114 LCD_D19 AF8 VOUT[0]_R_CR[5]
S115 LCD_D20 AF6 VOUT[0]_R_CR[6]
S116 LCD_D21 AF12 VOUT[0]_R_CR[7]
S117 LCD_D22 AE8 VOUT[0]_R_CR[8]
S118 LCD_D23 AC13 VOUT[0]_R_CR[9]
S119 GND44
S120 LCD_DE MAX V CPLD
S121 LCD_VS AB13 VOUT[0]_VSYNC
S122 LCD_HS AC11 VOUT[0]_HSYNC
S123 LCD_PCK AD12 VOUT[0]_CLK
S124 GND45
S125 LVDS0_P LVDS Transmitter
